Turbosystems, htx4068b1
15,495kr
Kan restnoteras
Turbosystems, htx4068b1
Power range: 700-850 HP
Displacement of the engine: 1.8-4.0 dm3Core: dual ceramic ball bearing
High performance turbocharger designed for heavy loads and high temperature.
Stainless steel housing and machined from solid aluminium compressor wheel
makes it durable and efficient solution for motorsport use.
Compressor side
- Compressor wheel: 10+0 blades machined from the solid aluminium
- Inducer: 68mm, Exducer: 84mm + extended tip
- Intake: 100mm
- Air outlet: 63mm
Turbine side
- Housing: twin scroll, AR: 1.02
- Turbine wheel: 10 blades
- Inducer: 76mm
- Exducer: 68mm
- Flange: T4 twin scroll
- Exhaust connection: 3" V-band clamp
| Vikt | 10 kg |
|---|---|
| Dimensioner | 40 × 40 × 40 cm |
