6266E Ball Bearing Turbo UP to 735HP

• Billet Compressor Wheel: 62mm / 82.2mm, 7+7 Blade
• Turbine Wheel: 66.1 / 74.17mm, 10 Blade
• Bearing System: Dual Ball Bearing (provides optimal turbo response & better durability by reducing the shaft motion)
• Compressor Cover Inlet/Outlet: 4.0” / 2.5” Hose
• Turbine Housing: T3 Open inlet & Vband Outlet 0.63A/R, T3 Open inlet & Vband Outlet 0.82A/R, T4 Open inlet & Vband Outlet Stainless Steel 0.63A/R, T4 Open inlet & Vband Outlet 0.96A/R, Vband Inlet&Outlet Stainless Steel 0.82A/R, Vband Inlet&Outlet 0.96A/R
• The internal oil feed port is 0.9mm
• Oil feed fitting: 1/8-27 NPSF(Drawing)
• Oil drain: T4 flange(Drawing)

Oil Drain Fitting:

10AN_STD

10AN_EXTENDED
